Industrial Drying Instant Cup Noodle Production Line 80000PCS8h Stainless Steel
Dongfang, the main propellant of Chinese noodle industrialization, has become the main equipment supplier and service provider of the domestic noodle industry, especially the backbone enterprises of noodle products. Over the years, the company’s products have been exported to more than 70 countries and regions.
Adjustments of Slitting and Noodle Wave Making:
Engagement of dough knife should be appropriate, which is usually 0.3mm-0.5mm. Shapes of wave laying can be adjusted to shaper gland weight.At the same time, speed of the tape of flower laying and dough knife should be adjusted to achieve the desired effect. The velocity ratio of flower laying tape and dough knife is about 1:4-7. Linear velocity of flower laying can be adjusted through frequency conversion.
Technical Parameters:
|
Type |
Non Fried Cup Noodle Production Line |
|
Shape |
Round Noodle Cakes |
|
Mixing Time |
Appr 20 min/time |
|
Cooling Time |
9 min |
|
After-sales Service Provided |
Engineers available to service machinery overseas |
|
Highlight |
High Accuracy Automatic |
The Adjustment of Roll Speed:
The revolving speed of motor is changed by the frequency converter to achieve the adjustment of roll speed. Frequency control is set up in two ways: automatic and manual. Automatic frequency control is appropriate for the situation that two motors accelerate or decelerate simultaneously. Well the manual frequency control applies to the speed regulation of the individual motor.
Our products are sold all over the world, you can rest assured.
